ErgoAV™ Black Extend and Tilt TV Table Mount

ErgoAV

Model #:

ERMTL3-01B

At a Glance

Product Dimensions 26.9"h x 34.2"w x 3.0"d

Large Extend Tilt Mount for TVs 46" to 100". Extension functionality allows for an increased tilting range and easy cable access. Tilting functionality helps reduce reflections and enhances the viewing experience. Level adjustment of ±3° enables the TV to be adjusted post-installation for a better viewing experience. The unique latching mechanism allows the TV to be securely attached and removed from the wall plate quickly and easily. Horizontal shift allows the TV to be moved horizontally on the wall plate to allow optimal placement on the wall. The open wall plate accommodates outlets and low-voltage pass-through. Safety tested and UL certification ensure peace of mind.Read More

$179.99

Get to know this product.

Product Overview

Product Overview

Fits 46” to 100” TVs up to 160 lbs in weight.

Open wall plate design offers space for outlets.

Level Adjustment ±3° allows the TV to be adjusted post-installation for a better viewing experience.

Enhanced movement provides up to +3 °/-12° tilt for the best viewing angle.

Extends up to 6.5” for easy cable access and retracts back to 2.94” for a low-profile look.

Pull cord lock allows easy and reliable locking or unlocking of your TV.

Useful Documents
Specification Sheet
Manual
Technical Drawing
Specifications

General Specs

Product Weight (lbs.)16
TiltYes
ColorBlack
Depth (in.)3.0
Width (in.)34.2
Height (in.)26.9
Mount TypeTilt
Low ProfileYes
Outdoor ApprovedNo
Smart CompatibleNo
Wifi CapableNo
TV Size's up to (in.)100
Weight Capacity (lbs.)160
Mounting LocationWall
Compatible Vesa Sizes100×100; 100×200; 100×300; 100×400; 200×100; 200×200; 200×300; 200×400; 300×100; 300×200; 300×300; 300×400; 400×100; 400×200; 400×300; 400×400; 600×100; 600×200; 600×300; 600×400; 600x500; 600x600
Manufacturer Warranty5 Year
Color Finish NameBlack
Shipping Depth (in.)16.9
Shipping Width (in.)36
Shipping Height (in.)3.3
Number Of Mounts1
