General Specs |
| Depth (in.) | 17.1 |
| Height (in.) | 5.1 |
| Width (in.) | 14.8 |
| Headset Jack | Yes |
| Wifi Capable | Yes |
| Bluetooth Capable | Yes |
| Product Weight (lbs.) | 19.6 |
| Color | Black |
| Shipping Depth (in.) | 20.4 |
| Shipping Width (in.) | 15.2 |
| Shipping Height (in.) | 8.2 |
General |
| Available colors: Premium Silver / Black | Yes / Yes |
| Metal Front Panel | Aluminum |
| Auto Power Off | Yes |
| Detachable Power Cable | Yes |
| Remote Control | RC-1246 |
| System Remote Function | Yes |
Inputs Outputs |
| Audio Inputs | RC-1246 |
| Digital in: USB-B / optical / coaxial / USB-A | 0 / 3 / 1 / 1 |
| Phono Input: MM / MC | Yes / Yes |
| Pre-out / Main-in | Subwoofer / No |
| Power Amp Direct IN | No |
| Gold plated Cinch | Yes |
| Speaker A / B | Yes |
| Remote Control Bus in / out | Yes (Remote Out) |
| Headphone Out | Yes |
| Headphone Gain Control (low / mid / high) | No |
Others |
| Low Noise OELD display | Yes |
| Source Direct | Yes |
| Display: Dimmer / Off | Yes / Yes |
| IR Learning for TV | Yes |
TECHNICAL SPECIFICATIONS |
| Total Harmonic Distortion | 0.01% (-3dB, 8ohm, 1kHz) |
| Power Amplifier Circuit | Advanced HC Single Push-Pull Circuit |
| Power Amp Output circuit Structure | Single Push-Pull with Darlington transistor |
| Pre Amplifier Circuit | Variable Gain Preamplifier |
| Volume | Electric - Controlled by Encoder |
| Bass Treble Mid Balance Control | Yes / Yes / No / Yes |
| Source Direct | Yes |
| Input Sensitivity: MM | 2.5mV / 47 kohm |
| Input Sensitivity: MC | 200 |
| Signal to Noise Ratio: MM/MC | 86 dB / 71 dB |
| Input Sensitivity: High level | 105 mV / 40kohms (Source Direct Off) |
| Signal to Noise Ratio: High level | 105dB |
| Treble Control | ± 8 dB at 10 kHz |
| Bass Control | ± 8 dB at 100 Hz |
